Aggregate Bunker Capacity: 6 m³ 200/3 with Vibrator.
Feeding Belt: (800x21000 mm) Cevus Belt.
Motor Power: 18.5 kW.
Reducer: Disan DG2 225 Locking Return.
Distributor Channel: Designed cylindrically to prevent material sticking.
Rotating Table: 4-point lubricated, conical bearing, specially designed to prevent dust ingress into the bearings.
Distributor Table Motor Reducer: 0.75 kW Coupled Reducer.
Mounted on the Distributor Table with wide welding.
Remote Control: 200 m range, Radio Frequency with 6 commands.
Aggregate Bunker Camera: Resistant to dust, mud, and all external factors, equipped with night vision and LED.
T.V. or Tablet: To view whether the aggregate bunker is empty or full, images from the camera on the bunker can be seen on the operator's screen via T.V or as a Tablet option for the wheeled loader user.
Benefits: As there is no need for your wheeled loader to drive up/down the ramp while loaded, the lifespan of the wheeled loader is extended, and fuel savings of 40% can be achieved. Since there is no need for a bunker loading ramp, savings can be made on concrete, rebar, formwork, and other installation costs.
